Place of Origin: Zhejiang, China
Brand Name: JYIELE
Model Number: YN-NBT002
Type: Self-locking
Material: Nylon, Nylon 66
Color: Natural,Black, Other Colors Upon Your Request
Size: Upon Your Request
Usage: Fixe The Cables
Operating Temperature: -35 ~ 85℃
Sample: Free Sample
Tensile Strength: 120LBS/55KGS
Flame Class: UL94V-2
Package: 100pcs/bag
Certification: CE CCC PAHS
1.Stainless steel barb provides consistent performance and reliability and infinite adjust ability through entire bundle range.
2.High Strength and low thread force.
3.Stippled strap body prevents lateral movement on the bundle.
4.Curved tip is easy to pick up from flat surfaces and allows faster initial threading to speed installation.
5.High loop Strength exceeds industry standards.
6.A variety of materials are avails able for specific applications.
7.For indoor or outdoor use.
| ITEM.NO. | LENGTH | WIDTH | Bundle diameterE(mm) | Min.loop tensile strength | ||
| INCH | MM | MM | LBS | KGS | ||
| 3X60 | 2 3/8″ | 60 | 2.5 | 2-11 | 18 | 8 |
| 3X80 | 3 3/16″ | 80 | 2.5 | 2-16 | 18 | 8 |
| 3X90 | 3 5/8” | 90 | 2.5 | 2-18 | 18 | 8 |
| 3X100 | 4″ | 100 | 2.5 | 2-22 | 18 | 8 |
| 3X120 | 4 3/4” | 120 | 2.5 | 2-30 | 18 | 8 |
| 3X140 | 5 1/2” | 140 | 2.5 | 2-33 | 18 | 8 |
| 3X150 | 6″ | 150 | 2.5 | 2-35 | 18 | 8 |
| 3X160 | 6 1/4” | 160 | 2.5 | 2-40 | 18 | 8 |
| 3X200 | 8″ | 200 | 2.5 | 3-50 | 18 | 8 |
| 4X200 | 8″ | 200 | 3.6 | 3-50 | 40 | 18 |
| 4X220 | 8 5/8” | 220 | 3.5 | 3-58 | 40 | 18 |
| 4X250 | 10″ | 250 | 3.6 | 3-65 | 40 | 18 |
| 4X280 | 11” | 280 | 3.5 | 3-70 | 40 | 18 |
| 4X300 | 11 5/8″ | 300 | 3.6 | 3-80 | 40 | 18 |
| 5X120 | 4 3/4″ | 120 | 4.8 | 3-24 | 50 | 22 |
| 5X180 | 7″ | 180 | 4.8 | 3-42 | 50 | 22 |
| 5X190 | 7 1/2” | 190 | 4.5 | 3-46 | 50 | 22 |
| 5X200 | 8″ | 200 | 4.8 | 3-50 | 50 | 22 |
| 5X250 | 10″ | 250 | 4.8 | 3-65 | 50 | 22 |
| 5X280 | 11” | 280 | 4.5 | 3-70 | 50 | 22 |
| 5X300 | 12″ | 300 | 4.8 | 3-82 | 50 | 22 |
| 5X350 | 13 3/4″ | 350 | 4.8 | 3-90 | 50 | 22 |
| 5X380 | 15″ | 380 | 4.8 | 3-102 | 50 | 22 |
| 5X400 | 15 3/4″ | 400 | 4.8 | 3-105 | 50 | 22 |
| 8X200 | 8″ | 200 | 7.2 | 3-50 | 120 | 55 |
| 8X250 | 10″ | 250 | 7.2 | 4-63 | 120 | 55 |
| 8X270 | 10 5/8” | 270 | 6 | 4-65 | 65 | 30 |
| 8X300 | 11 5/8″ | 300 | 7.2 | 4-82 | 120 | 55 |
| 8X350 | 13 3/4″ | 350 | 7.2 | 4-90 | 120 | 55 |
| 8X370 | 14 1/4″ | 370 | 7.2 | 4-98 | 120 | 55 |
| 8X400 | 15 3/4″ | 400 | 7.2 | 4-105 | 120 | 55 |
| 8X450 | 17 3/4″ | 450 | 7.2 | 4-118 | 120 | 55 |
| 8X500 | 19 11/16″ | 500 | 7.2 | 4-150 | 120 | 55 |
| 8X550 | 21.6 | 550 | 7.2 | 4-165 | 120 | 55 |
| 9X530 | 20 3/4” | 530 | 9 | 8-155 | 175 | 80 |
| 9X550 | 21 1/16″ | 550 | 9 | 8-160 | 175 | 80 |
| 9X600 | 23 5/8″ | 600 | 9 | 8-170 | 175 | 80 |
| 9X650 | 25 9/16″ | 650 | 9 | 8-190 | 175 | 80 |
| 9X700 | 27 1/2″ | 700 | 9 | 10-205 | 175 | 80 |
| 9X760 | 30” | 760 | 9 | 10-225 | 175 | 80 |
| 9X920 | 36 1/4″ | 920 | 9 | 10-265 | 175 | 80 |
| 9X1020 | 40 1/6″ | 1020 | 9 | 10-295 | 175 | 80 |
| 9X1150 | 45 1/4″ | 1150 | 9 | 10-310 | 175 | 80 |
| 9X1200 | 47 1/5″ | 1200 | 9 | 10-340 | 175 | 80 |
| 10X450 | 17 3/4” | 450 | 10 | 10-125 | 200 | 91 |
| 10X500 | 19 11/16” | 500 | 10 | 12-150 | 200 | 91 |
